INGKE YKGU-22302NL 2-2301994-7 TE

INGKE YKGU-22302NL 100% cross 2-2301994-7 TE

Part No.: 2-2301994-7 TE
INGKE Part No.: YKGU-22302NL
Made in China: INGKE Technology
Description: 2-2301994-7 TE 1X1 Ports RJ45 Connector
MOQ: 1PCS
Lead Time: 1-2 Weeks

Connector Type: RJ45
Number of Ports: 1
Number of Rows: 1
Applications: 1G Base-T, AutoMDIX
Mounting Type: Through Hole
Orientation: 90° Angle (Right)
Termination: Solder
LED Color:Green/Yellow
Contact Base Material :Copper Alloy
PCB Mount Retention Type :Boardlock
Tab Direction: Up
Shield Material :Brass
Operating Temperature: -40°C ~ 85°C
Housing Color :Black
Housing Material :Liquid Crystal Polymer (LCP)
Categories:Connectors, Interconnects, Modular Connectors, Modular Connector Jacks With Magnetics
MSL: 1 (Unlimited)
Lead Free, RoHS Compliant
INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
