INGKE YKGU-26114NL 0826-1K1T-43-F Bel

INGKE YKGU-26114NL 100% cross 0826-1K1T-43-F Bel

Part No.: 0826-1K1T-43-F Bel

INGKE Part No.: YKGU-26114NL

Made in China: INGKE Technology

Description: 0826-1K1T-43-F Bel 1 Port RJ45 Through Hole 10/100/1000 Base-T, AutoMDIX

MOQ: 1PCS

Lead Time: 1-2 Weeks

Connector Type:RJ45
Tab Direction:Up

Number of Ports:1
Number of Rows:1

Applications:10/100/1000 Base-T, AutoMDIX
LED Color:Green, Yellow - Green

Number of Cores per Jack:8
Shielding:Shielded, EMI Finger

Height Above Board:0.536" (13.61mm)

Features:Board Guide
Mounting Type:Through Hole
Orientation:90° Angle (Right)
Termination:Solder
Operating Temperature:0°C ~ 70°C

Contact Material:Phosphor Bronze
Contact Finish:Gold

Contact Finish Thickness:50.0µin (1.27µm)
Shield Material:Copper Alloy
Housing Material:Polyamide (PA46), Nylon 4/6

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months

Factory with UL, supplier of Marvell & Honeywell
