INGKE YKJ-24967042NL 2496704-2 TE

INGKE YKJ-24967042NL 100% cross 2496704-2 TE

Part No.: 2496704-2 TE

INGKE Part No.: YKJ-24967042NL

Made in China: INGKE Technology

Description: 2496704-2 TE RJ45 W/O MAGNET 2X1 LED PLATING T 30

MOQ: 1PCS
Lead Time: 1-2 Weeks

Gender: Jack (Female)
USOC Codes: RJ45
Configuration: 2x1
Number of Positions / Contacts per Port: 8P8C
Shielding: Shielded
Performance Category: Cat 3
Mounting Style: PCB Mount
Mounting Angle: Right Angle
Termination Style: Through Hole
Current Rating: 1.5 A
Voltage Rating: 57 VDC
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Color: Black
LED L / R Color: Yellow, Green
Tab Direction: Tab Up and Tab Down
Application: Power and Signal
Brand: TE Connectivity
Contact Material: Phosphor Bronze
Contact Plating: Gold
Country of Assembly: Not Available
Country of Diffusion: Not Available
Country of Origin: CN
Flammability Rating: UL 94 V-0
Insulation Resistance: 500 MOhms
Mounting Direction: Right Angle
Pitch: 1.27 mm
Product Type: Modular Connectors / Ethernet Connectors

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
