INGKE YKJ-900008NL SS-90000-008 Stewart

INGKE YKJ-900008NL 100% cross SS-90000-008 Stewart

Part No.: SS-90000-008 Stewart

INGKE Part No.: YKJ-900008NL

Made in China: INGKE Technology

Description: SS-90000-008 Stewart RJ45 over USB 3.0 Type A passive jack Tab Up Y/G LEDs

MOQ: 1PCS
Lead Time: 1-2 Weeks

Gender: Jack (Female)
USOC Codes: RJ45
Configuration: 1x1
Number of Positions / Contacts per Port: 8P8C
Shielding: Shielded, EMI Fingers
Mounting Style: Through Hole
Mounting Angle: Right Angle
Termination Style: Solder
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Color: Black
LED L / R Color: Yellow / Green
Tab Direction: Tab Up
Brand: Stewart Connector
Contact Material: Copper Alloy
Contact Plating: Gold
Country of Assembly: Not Available
Country of Diffusion: CN
Country of Origin: CN
Flammability Rating: UL94 V-0
Mounting Direction: Horizontal
Number of Contacts: 8 Contact
Number of Ports: 1 Port
Number of Positions: 8 Position
Operating Temperature Range: - 40 C to + 85 C
Pitch: 2.54 mm
Product Type: Modular Connectors / Ethernet Connectors

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
