INGKE YKJD-365008NL CRJ008-MG-TH Same Sky

INGKE YKJD-365008NL 100% cross CRJ008-MG-TH Same Sky

Part No.: CRJ008-MG-TH Same Sky

INGKE Part No.: YKJD-365008NL

Made in China: INGKE Technology

Description: CRJ008-MG-TH Same Sky 8P10C, gold flash, shield, spring tabs, no LED, magnetic

MOQ: 1PCS
Lead Time: 1-2 Weeks

Gender: Jack (Female)
USOC Codes: RJ45
Configuration: 1x1
Number of Positions / Contacts per Port: 8P10C
Shielding: Shielded
Performance Category: Cat 5
Mounting Style: Through Hole
Mounting Angle: Right Angle
Termination Style: Solder
Current Rating: 1.5 A
Voltage Rating: 150 VAC
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 70 C
Color: Black
Tab Direction: Tab Down
Packaging: Tray
Application: 10/100 Base-T PoE
Contact Material: Phosphor Bronze
Contact Plating: Gold
Country of Assembly: Not Available
Country of Diffusion: Not Available
Flammability Rating: UL 94 V-0
Insulation Resistance: 500 MOhms
Mounting Direction: Horizontal
Product Type: Modular Connectors / Ethernet Connectors

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
