INGKE YKJV-308010NL RJHSE3080A1 Amphenol

INGKE YKJV-308010NL 100% cross RJHSE3080A1 Amphenol

Part No.: RJHSE3080A1 Amphenol

INGKE Part No.: YKJV-308010NL

Made in China: INGKE Technology

Description: RJHSE3080A1 Amphenol RJ45 Vertical No Shield/LEDs

MOQ: 1PCS
Lead Time: 1-2 Weeks

Gender: Jack (Female)
USOC Codes: RJ45
Configuration: 1x1
Number of Positions / Contacts per Port: 8P8C
Shielding: Unshielded
Performance Category: Cat 5
Mounting Style: Through Hole
Mounting Angle: Vertical
Termination Style: Solder
IP Rating: IP20
Current Rating: 1.5 A
Voltage Rating: 125 VAC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 85 C
Application: 10/100 Base-T
Brand: Amphenol Commercial Products
Contact Material: Phosphor Bronze
Contact Plating: Gold
Country of Assembly: Not Available
Country of Diffusion: Not Available
Country of Origin: CN
Flammability Rating: UL 94 V-0
Insulation Resistance: 500 MOhms
Mating Cycles: 750 Cycles
Product Type: Modular Connectors / Ethernet Connectors

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
