INGKE YKKU-31003NL 85793-1003 Molex

INGKE YKKU-31003NL 100% cross 85793-1003 Molex

Part No.: 85793-1003 Molex

INGKE Part No.: YKKU-31003NL

Made in China: INGKE Technology

Description:85793-1003 Molex 1 Port RJ45 Through Hole 10/100/1000 Base-T, AutoMDIX

MOQ: 1PCS

Lead Time: 1-2 Weeks

Connector Type:RJ45
Number of Ports:1
Number of Rows:1
Applications:10/100/1000 Base-T, AutoMDIX
LED: Green, Orange - Green
Shielding:Shielded, EMI Finger
Mounting Type:Through Hole
Orientation:90° Angle (Right)

Termination:Solder

Number of Cores per Jack:8
Tab Direction:Up
Operating Temperature:0°C ~ 70°C
Contact Material: Phosphor Bronze
Features:Board Lock
Contact Finish:Gold
Housing Material: Polybutylene Terephthalate (PBT)
Contact Finish Thickness:30.0µin (0.76µm)

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months

Factory with UL, supplier of Marvell & Honeywell
