INGKE YKSD-64112NL 1664112 Phoenix

INGKE YKSD-64112NL 100% cross 1664112 Phoenix

Part No.: 1664112 Phoenix

INGKE Part No.: YKSD-64112NL

Made in China: INGKE Technology

Description: 1664112 Phoenix 1 Port RJ45 Through Hole 1G Base-T, AutoMDIX

MOQ: 1PCS
Lead Time: 1-2 Weeks

Gender: Jack (Female)
USOC Codes: RJ45
Configuration: 1x1
Shielding: Shielded, EMI Finger

Features:Board Guide
Number of Cores per Jack:8
Termination Style: Through Hole

Orientation:90° Angle (Right)
Height Above Board:0.537" (13.64mm)
Termination:Solder
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C

LED L / R Color: Does Not Contain LED

Applications:1G Base-T, AutoMDIX
Contact Material: Phosphor Bronze
Contact Plating: Gold

Tab Direction:Down

Contact Finish Thickness:30.0µin (0.76µm)
Number of Ports: 1 Port
Number of Rows: 1 Position
Housing Material:Liquid Crystal Polymer (LCP)
Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
