YKG-50843NL HX5084NLT Pulse

INGKE YKG-50843NL 100% cross HX5084NLT Pulse

Part No.:HX5084NLT

INGKE Part No.: YKG-50843NL

Made in China: INGKE Technology

Description: HX5084NLT Pulse 350µH LAN 10/100/1000 Base-T Pulse Transformer

MOQ: 1PCS

Lead Time: within 1 week

Product: LAN Transformers

Termination Style: SMD/SMT

Frequency Range: 1 MHz to 125 MHz

Inductance: 350µH

Isolation Voltage: 1.5 kV

Length: 15.24mm

Width: 9.78mm

Height: 4.14mm

Application: 1000 Base-T

Operating Temperature: -40°C ~ +105°C

Product Category: Audio Transformers / Signal Transformers

Moisture Sensitivity Level (MSL): 1 (Unlimited)

RoHS Compliant and REACH

100% compatible, 100% test,  warranty for 60 months

Factory with UL, supplier of Marvell & Honeywell

Chinese UL factory for producing HX5084NLT Pulse LAN Transformers
