YKGT-S28-10G S28-10G-25G-SR-85C Dell

S28-10G-25G-SR-85C Dell 100% cross INGKE YKGT-S28-10G

Part Number: S28-10G-25G-SR-85C Dell

Verdor Name: INGKE

100% Dell Compatible

Hot-pluggable SFP28 transceiver module

Dual Rate 10G/25GBASE-SR 10G/25G Ethernet

Up to 25.78 Gbps bi-directional data links

Up to 100m over OM4 Multimode Fiber (MMF)

Up to 70m over OM3 Multimode Fiber (MMF)

850nm VCSEL laser and PIN/TIA receiver

Maximum power dissipation < 1.2W

Metal enclosure, for lower EMI

Single 3.3V power supply

Duplex LC connector

I2C management interface

Industrial operating temperature range: -40°C to +85°C

Part Status: Active

RoHS Comp: Yes

MSL: 1 (Unlimited)

Lead time: 1-2 weeks

Product Category: Fibre Optic Transmitters, Receivers, Transceivers

Target Users: Businesses, Home users, Industrial users

Use Cases: Data transmission, Home networking, Industrial control, IoT applications, Office networking
