Product Description:
INGKE YKT-326611NL 100% compatible with RJMG3266N11G0ER Amphenol ICC
Part No.: RJMG3266N11G0ER Amphenol ICC
INGKE Part No.: YKT-326611NL
Made in China: INGKE Technology
Description: RJMG3266N11G0ER Amphenol ICC 12 Ports 10G Base-T
MOQ: 1PCS
Lead Time: 1-2 Weeks
Connector Type: RJ45
Number of Ports: 12
Number of Rows: 2
Applications: 10G Base-T, AutoMDIX
Mounting Type: Panel Mount, Through Hole
Orientation: 90° Angle (Right)
Termination: Press-Fit
Height Above Board: 0.989" (25.12mm)
LED Color: Does Not Contain LED
Number of Cores per Jack: 8
Shielding: Shielded, EMI Finger
Features: Board Guide, Filter, Light Pipe
Tab Direction: Up and Down
Contact Material: Phosphor Bronze
Contact Finish: Gold
Operating Temperature: 0°C ~ 70°C
Shield Material: Stainless Steel
Housing Material: Thermoplastic
Categories:Connectors, Interconnects,Modular Connectors,Modular Connector Jacks With Magnetics
MSL: 1 (Unlimited)
Lead Free, RoHS Compliant
INGKE UL No.: E530462
100% compatible, 100% test, warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
