INGKE YKJU-94619NL TMJK9461A97NL Taoglas

INGKE  YKJU-94619NL100% cross TMJK9461A97NL Taoglas

Part No.: TMJK9461A97NL Taoglas

INGKE Part No.: YKJU-94619NL

Made in China: INGKE Technology

Description: TMJK9461A97NL Taoglas 1 Port RJ45 Through Hole 10/100 Base-T, AutoMDIX

MOQ: 1PCS

Lead Time: 1-2 Weeks

Connector Type:RJ45
Tab Direction:Up

Number of Ports:1
Number of Rows:1
Applications:10/100 Base-T, AutoMDIX
LED Color:Yellow, Green - Green
Shielding:Shielded, EMI Finger
Features:Board Guide
Mounting Type:Through Hole
Orientation:90° Angle (Right)
Termination:Solder

Height Above Board:0.445" (11.30mm)

Number of Cores per Jack:8
Operating Temperature:-40°C ~ 85°C
Contact Material: Phosphor Bronze
Contact Finish:Gold

Contact Finish Thickness:6.00µin (0.152µm)

Housing Material:Thermoplastic

Shield Material:Brass, Copper Alloy

Lead Free, RoHS Compliant

INGKE UL No.: E530462

100% compatible, 100% test,  warranty for 60 months

Factory with UL, supplier of Marvell & Honeywell
